CONTROLS
Input: Connect 1/4” instrument cable from guitar or pedals to the ABY+ here
Output: Connect 1/4” instrument cables from the outputs to your amps or pedals.
Lift/Ground Switch: Use this switch to disconnect signal grounds.
Iso/Direct Switch: Use this switch to engage the isolation transformer on the B output to reduce hum and noise caused by a ground loop. Ground switch must be engaged when using transformer.
A/B Footswitch: Switches which output the input is routed to, either A or B.
Y Footswitch: Selects whether the input is routed to a single output or both outputs simultaneously.
Power: This pedal takes a standard 9V DC Center-Negative power supply with a 2.1mm negative center barrel. Current: 85mA
Warranty: This device has a one year warranty. If it fails or gives your problems, please email tre@tre_audio.com.
